Agricultural Dryer

Used to dry various agricultural products, such as beet, pumpkin, cabbage, chopped green onion, yam, potato, carob, etc.

Output: ranges from 3 tons to 20 tons per day

Layers: ranges from 1 layer to 7 layers

Length: ranges from 6 meters to 32 meters

Belt width: ranges from 1.7 meters to 3 meters

Customization is also available


Introduction to belt agricultural dryer:

The belt agricultural dryer machine has advantages of large output and good drying effect. Agricultural products drying equipment can be used to dry various agricultural products, such as beet, pumpkin, cabbage, chopped green onion, yam, potato, carob, etc. So it's also called beet drying machine, pumpkin drying machine and chopped green onion drying machine.

The appearance of belt agricultural drying machine greatly improves the storage cycle of various agricultural products, and promotes the large-scale and industrialized development of cultivation and processing of agricultural products. The whole drying process is without any pollution, ensuring the quality and taste of the dried agricultural products.

Advantages and characteristics of agricultural dryer machine:

1. Quickly complete the drying process at one time, so that the temperature in the agricultural drying machine is always lower than 50°C, and the dried agricultural products completely retain their nutrients, bright colors and fragrance.

2. The temperature of the hot air can be set according to the needs of material to be dried, and the temperature can be freely controlled between 40-120℃, so that the color of materials after being dried will not be changed.

3. Each layer is equipped with material stoppers and material guiders to prevent materials falling from the upper layer to the next layer; the materials will be cyclically turned inside the agricultural dryer machine and dried layer by layer to ensure the consistent drying degree of  materials.

4. The feeding conveyor of the beet dryer machine, pumpkin drying machine and chopped green onion drying machine is equipped with a material homogenizing device, which can adjust the thickness of the material spreading according to the different bulk densities of materials,  and maximize the feeding to ensure the output of the agricultural product drying equipment.

5. The transmission part adopts a variable-frequency speed-regulating motor, which can control the drying time according to the moisture content of materials, which improves the efficiency under the premise of ensuring the drying effect.

Technical Data:

Model GX-6 GX-8 GX-9 GX-10 GX-12
Layer 4
Drying temperature 0~120℃
Drying time 0.1~5 hours
Moisture reduce 85%~8% (customized)
Drying area 29m2 45m2 51m2 57m2 69m2
Total power 14.55kw 19.25kw 19.95kw 26.95kw 27.75kw
Overall dimension(L*W*H) 6000*2200*2300 mm 8000*2200*2300 mm 9000*2200*2300 mm 10000*2200*2400 mm 12000*2200*2400 mm
